CDIT-3稱重傳感器詳細信息請點擊：英國LCMsystems稱重傳感器：
產品品牌：英國LCMsystems（LOADCELL）
產品類別：不銹鋼薄型高精度壓式
產品系列：LCM輪輻式CDIT-3系列稱重傳感器
產品型號：CDIT-3-100kg,CDIT-3-250kgkg,CDIT-3-500kg, CDIT-3-1000kg, CDIT-3-2500kg, CDIT-3-5000kg,CDIT-3-7500kg,CDIT-3-10te, CDIT-3-20te, CDIT-3-30te, CDIT-3-50te, CDIT-3-75te,CDIT-3-100te,CDIT-3-150te,CDIT-3-200te
產品描述：該CDIT-3系列稱重傳感器都被設計為各種測力稱重應用的空間是有限的。該CDIT-3是由不銹鋼構成并具有全焊接結構，提供耐腐蝕性的使用高水平的惡劣環境中，與環境密封到IP68。該系列傳感器可與范圍涵蓋0100公斤，以0-200te。有許多應用相適應的CDIT-3，包括受限制高度稱重應用，一般測力和印刷機校準。有安裝板，負載上限，可供范圍可達30TE完整的稱重組裝配件及負載上限版本。LCM系統可以提供CDIT-3在其單獨或與我們的任何儀器范圍，以提供更完整的方案。請咨詢我們的技術部門在合適的儀器儀表解決方案所需的任何意見。
英國LCMsystems CDIT-3稱重傳感器特點
▲范圍100千克到200t
▲不銹鋼焊接結構
▲低高度
▲精度<±0.02％
▲環境密封IP68
英國LCMsystems CDIT-3稱重傳感器技術參數
|
Rated Load (FSO)
|
100, 250, 500, 1000, 2500, 5000, 7500 kg
10, 20, 30, 50, 75, 100, 150, 200 te
|
|
Overload Range
|
150% FSO
|
|
Ultimate Breaking Load
|
> 300% FSO
|
|
Output
|
2mV/V (±0.1%)
|
|
Zero Balance
|
<±1% FSO
|
|
Combined Error
|
≤±0.02% FSO (equivalent to OIML R60, Class C3)
|
|
Non-Repeatability
|
≤±0.01% FSO
|
|
Creep (at nominal load)
|
<±0.03% FSO over 30 minutes
<0±0.01% FSO over 20-30 minutes
|
|
Maximum Transverse Load
|
50% FSO
|
|
Excitation Voltage
|
10vdc recommended (18vdc maximum)
|
|
Input Resistance
|
700Ω ±3Ω
|
|
Output Resistance
|
7000Ω ±3Ω
|
|
Insulation Resistance
|
>5GΩ @ 50vdc
|
|
Compensated Temperature Range
|
-10 to +40 °C
|
|
Operating Temperature Range
|
-20 to +70 °C
|
|
Storage Temperature Range
|
-20 to +80 °C
|
|
Zero Temperature Coefficient
|
≤±0.0025% FSO/°C
|
|
Span Temperature Coefficient
|
≤±0.0017% FSO/°C
|
|
Environmental Protection Level
|
IP68
|
|
Electrical Connection
|
Glanded PVC cable - 3 metres long
|
英國LCMsystems CDIT-3稱重傳感器技術尺寸
Ranges 100kg to 200te
Stainless Steel welded construction
Low Height
Accuracy <±0.02%
Environmentally Sealed to IP68
The CDIT-3 series of Load Cells have been designed for a wide range of force measurement and weighing applications where space is limited.
The CDIT-3 is constructed from stainless steel and has a fully welded construction, offering a high level of corrosion resistance for use in harsh environments, with environmental sealing to IP68.
This range of load cells is available with ranges covering 0-100kg to 0-200te.
There are many applications suited to the CDIT-3, including restricted height weighing applications, general force measurements and press calibration.
There are mounting plate, load cap and complete weighing assembly accessories available for ranges up to 30te, and load cap versions.
LCM Systems can provide the CDIT-3 on its own or combined with any of our instrumentation range, to offer a more complete package. Please consult our technical department for any advice required on suitable instrumentation solutions.
